QUADBOOL is the only logic module you'll ever need. Each of the four "quads" operates independently and can apply AND, OR, NOR, XAND, XOR, XNOR logical operators on its two inputs. This allows you to create infinite rhymthic variations, complex clocks, and even audio-rate weirdness. Check out DivKid's excellent video on logic to see all the possibilites!
Each of the lighted button mirrors the output jack so you can see the effect that the selected logic operator is having. QUADBOOL also allows you to switch any/all of the quads to output manual gates when pressing the button. We tried to keep the interface simple and functional, so there are no menus to dive into. There *is*, however, a secret boot-up configuration menu that allows you to customize many aspects of how the module behaves: Configure the order in which the operators are selected, dedicate each quad to a specific operator, and other settings to make the module fit your needs perfectly.
Depth: 35mm (+9mm for the power cable)
Also Includes: (1) 20cm IDC power cable; (2) M3 x.5mm x 6mm mounting screws
